Model |
Item |
|
E23-8 |
||
|
Main parameters |
Working weight |
KG |
22650 |
||
|
|
Standard bucket capacity |
m³ |
1.1 |
||
|
Main Configurations |
Engine |
Brand |
|
CUMMINS |
CUMMINS |
|
|
|
Engine Power |
KW/rpm |
133KW/2000rpm |
133KW/2000rpm |
|
|
|
Intake mode |
|
Turbocharge |
Turbocharge |
|
|
|
Emission standard |
|
TIER 2 |
TIER 2 |
|
|
Main pump |
Brand |
|
EDDIE |
KPM |
|
|
|
Rated pressure |
MPa |
34.3 |
37.3 |
|
|
|
Flow |
L/min |
260×2 |
228×2 |
|
|
Main control valve |
Brand |
|
EDDIE |
KPM |
|
|
|
Rated flow |
L/min |
343 |
300 |
|
|
Slewing motor |
Brand |
|
EDDIE |
KPM |
|
|
|
Rated pressure |
MPa |
25.5 |
25.5 |
|
|
Traveling motor |
Brand |
|
EDDIE |
EDDIE |
|
|
|
Rated pressure |
MPa |
34.3 |
34.3 |
|
技 术 性 能 指 标 |
Standard bucket capacity |
m³ |
1.1 |
||
|
|
Standard Bucket Rod |
mm |
2925 Enhanced |
||
|
|
Boom length |
mm |
5700 Enhanced |
||
|
|
Bucket digging force |
KN |
148 |
||
|
|
Stick digging force |
KN |
108 |
||
|
|
Track Frame Gauge |
mm |
2380 |
||
|
|
Track Frame Ground Length |
mm |
3655 |
||
|
|
Track plate width |
mm |
600 |
||
|
|
Ground pressure |
KPa |
46.7 |
||
|
|
Number of supporting wheels |
PCS |
2*9 |
||
|
|
Number of chain track sections |
PCS |
2*49 |
||
|
|
Traction force |
KN |
220 |
||
|
|
Traveling speed |
KM/h |
4.7/3.2 |
||
|
|
Slewing speed |
R/min |
12 |
||
|
|
Climbing capacity |
%/° |
70%/35° |
||
|
|
Fuel tank capacity |
L |
350 |
||
|
|
Cooling System |
L |
28 |
||
|
|
Engine oil capacity |
L |
21.5 |
||
|
|
Hydraulic oil tank |
L |
230(400) |
||
|
|
Overall length |
mm |
9615 |
||
|
|
Overall width |
mm |
2980 |
||
|
|
Overall height |
mm |
3045 |
||
|
|
Max.digging height |
mm |
10075 |
||
|
|
Max.unloading height |
mm |
7165 |
||
|
|
Max.digging depth |
mm |
6515 |
||
|
|
Max.vertical digging depth |
mm |
5800 |
||
|
|
Max.digging radius |
mm |
9865 |
||
|
|
Max. digging radius at ground level |
mm |
9685 |
||
