MAIN SPECIFICATIONS

1

Length of fork tines

1220mm

2

Rated load

4000 kg

3

Boom lifting time (no load/full load)

14.4/18.9s

4

Boom lowering time (no load/full load)

16.9/19.8s

5

Telescopic boom extend/retract time

20.4s/18.8s

6

time

7s

7

Speed

FⅠ/RⅠ

10km/h

FⅠ/RⅠ

30km/h

8

Min.Turning Radius Outside of Bucket

5500±50mm

9

Length (Fork tines flat on the ground)

7500±50mm

10

Width (Bucket width)

2420±10mm

11

Height (top of cab)

2810±20mm

12

Wheelbase

3300±10mm

13

Wheel tread

1980±10mm

14

Min.Ground clearance

 440mm

15

Max.lifting height

17500±50mm

16

Operating weight

13000Kg

Engine

1

Model

QSF3.8-C140

2

Rated power/Speed

104KW /2200r/min

3

Displacement

3.8 L

4

Fuel consumption In calibration conditions

230g/kw·h

Transmission system

1

Gearbox

Model

CA587914S

Type

Hydrostatic

2

Axle

Model

Front/CA599663S
Rear/CA599664S

Type

Wet brake

Total Deceleration Ratio

20.14

Axle load

25000kg/25000kg

Braking torque

25120 N.m

3

Tire

Tire Model

440/80-24

Tire Type

Pneumatic tire

Brake system

1

Traveling Brake

Type

Wet brake

Braking pressure

4.4Mpa

2

Parking brake

Type

Spring brake hydraulic release

Steering system

1

Type

Fully hydraulic steering

2

Working pump

RB02849089

3

Displacement

 63ml/r

4

System pressure

20 MPa

5

Steering angle

28°
